Azure NetApp Files - Simply Explained

1
00:00:00,000 --> 00:00:02,360
Azure already gives you plenty of storage options,

2
00:00:02,360 --> 00:00:04,080
blob, files, disk.

3
00:00:04,080 --> 00:00:06,240
So why does Azure NetApp files even exist?

4
00:00:06,240 --> 00:00:08,720
That's the first question people ask when they hear about it.

5
00:00:08,720 --> 00:00:09,560
And it's a fair one.

6
00:00:09,560 --> 00:00:11,400
Microsoft keeps adding storage services

7
00:00:11,400 --> 00:00:13,800
and it can feel like a new option appears every quarter.

8
00:00:13,800 --> 00:00:14,760
So why another one?

9
00:00:14,760 --> 00:00:15,600
Here's the thing.

10
00:00:15,600 --> 00:00:18,320
Most Azure storage handles general use just fine.

11
00:00:18,320 --> 00:00:20,640
Web apps, file shares, backups,

12
00:00:20,640 --> 00:00:22,760
the everyday things that keep a business running,

13
00:00:22,760 --> 00:00:24,560
but some workloads don't fit that mold.

14
00:00:24,560 --> 00:00:25,800
They need ridiculous speed.

15
00:00:25,800 --> 00:00:28,080
They need consistent performance under pressure,

16
00:00:28,080 --> 00:00:30,600
and they can't afford extra milliseconds of delay.

17
00:00:30,600 --> 00:00:32,760
Azure NetApp files is built specifically

18
00:00:32,760 --> 00:00:34,040
for those workloads.

19
00:00:34,040 --> 00:00:35,320
By the end of this episode,

20
00:00:35,320 --> 00:00:37,200
you'll know exactly what A and F is,

21
00:00:37,200 --> 00:00:40,000
when to use it, and when to stick with something simpler.

22
00:00:40,000 --> 00:00:41,160
We'll cover what it actually is,

23
00:00:41,160 --> 00:00:43,120
the three main use cases where it shines

24
00:00:43,120 --> 00:00:44,920
and how it compares to Azure files.

25
00:00:44,920 --> 00:00:46,920
Let's start with a simple definition.

26
00:00:46,920 --> 00:00:49,320
What Azure NetApp files actually is.

27
00:00:49,320 --> 00:00:51,000
Azure NetApp files is a managed,

28
00:00:51,000 --> 00:00:53,400
high performance enterprise file storage service

29
00:00:53,400 --> 00:00:55,000
that lives right inside Azure.

30
00:00:55,000 --> 00:00:56,640
This is not some third party add-on

31
00:00:56,640 --> 00:00:58,200
or something you bolt on later.

32
00:00:58,200 --> 00:00:59,960
It's the first party Microsoft service

33
00:00:59,960 --> 00:01:01,600
fully built into the Azure portal,

34
00:01:01,600 --> 00:01:02,840
but what sets it apart?

35
00:01:02,840 --> 00:01:05,440
Under the hood, it runs on NetApp technology.

36
00:01:05,440 --> 00:01:07,160
The same storage system that's been powering

37
00:01:07,160 --> 00:01:09,240
on premises data centers for decades,

38
00:01:09,240 --> 00:01:11,120
NetApp has been doing enterprise file storage

39
00:01:11,120 --> 00:01:12,680
since the 1990s.

40
00:01:12,680 --> 00:01:14,840
They understand fast and reliable data.

41
00:01:14,840 --> 00:01:17,560
Microsoft partnered with them to bring that expertise

42
00:01:17,560 --> 00:01:19,480
into Azure as a managed service.

43
00:01:19,480 --> 00:01:20,720
So what does that mean for you?

44
00:01:20,720 --> 00:01:23,240
A and F supports both SMB and NFS protocols

45
00:01:23,240 --> 00:01:24,320
right out of the box.

46
00:01:24,320 --> 00:01:26,560
Windows workloads, Linux workloads,

47
00:01:26,560 --> 00:01:27,680
it handles both.

48
00:01:27,680 --> 00:01:29,280
You don't have to choose one or the other.

49
00:01:29,280 --> 00:01:31,320
The same volume can serve both types of clients

50
00:01:31,320 --> 00:01:32,240
if you need it.

51
00:01:32,240 --> 00:01:34,080
Performance is where it really stands out.

52
00:01:34,080 --> 00:01:35,680
We're talking sub millisecond latency

53
00:01:35,680 --> 00:01:38,160
and massive throughput, not fast enough.

54
00:01:38,160 --> 00:01:40,200
It's genuinely blazing fast.

55
00:01:40,200 --> 00:01:41,160
Here's an analogy.

56
00:01:41,160 --> 00:01:43,320
If Azure files is the reliable family sedan

57
00:01:43,320 --> 00:01:44,920
that gets you where you need to go,

58
00:01:44,920 --> 00:01:46,720
Azure NetApp files is the sports car,

59
00:01:46,720 --> 00:01:48,640
built for speed and it handles unlike anything else

60
00:01:48,640 --> 00:01:49,480
in the garage.

61
00:01:49,480 --> 00:01:50,920
And the best part, it's fully managed.

62
00:01:50,920 --> 00:01:52,760
No patching service, no replacing hardware.

63
00:01:52,760 --> 00:01:54,200
You just create a volume,

64
00:01:54,200 --> 00:01:56,640
choose your performance tier and start using it.

65
00:01:56,640 --> 00:01:58,520
Azure and NetApp take care of the rest,

66
00:01:58,520 --> 00:02:00,320
but why would you need a sports car for storage?

67
00:02:00,320 --> 00:02:03,200
Let's look at the problems regular storage can't solve.

68
00:02:03,200 --> 00:02:06,760
The problems, regular storage can't solve.

69
00:02:06,760 --> 00:02:09,560
Most cloud storage handles everyday IT, just fine.

70
00:02:09,560 --> 00:02:11,600
Web apps, file shares, backups.

71
00:02:11,600 --> 00:02:12,760
For most people that's enough,

72
00:02:12,760 --> 00:02:14,120
you don't need a Formula One engine

73
00:02:14,120 --> 00:02:15,720
to drive to the grocery store.

74
00:02:15,720 --> 00:02:17,280
But some workloads are different.

75
00:02:17,280 --> 00:02:18,880
Think of them like demanding athletes

76
00:02:18,880 --> 00:02:21,120
who need every millisecond and can't afford to wait.

77
00:02:21,120 --> 00:02:21,960
Here's the problem.

78
00:02:21,960 --> 00:02:24,160
High latency kills database performance.

79
00:02:24,160 --> 00:02:25,920
A few extra milliseconds on a log ride

80
00:02:25,920 --> 00:02:28,360
can slow down an entire transaction system.

81
00:02:28,360 --> 00:02:30,040
Low throughput chokes simulations,

82
00:02:30,040 --> 00:02:32,320
turning jobs that should take hours into days.

83
00:02:32,320 --> 00:02:34,040
Inconsistent IOPS is another issue.

84
00:02:34,040 --> 00:02:36,040
It frustrates VDI users the most.

85
00:02:36,040 --> 00:02:37,440
One minute everything's fine.

86
00:02:37,440 --> 00:02:39,960
The next, the desktop lags because storage can't keep up.

87
00:02:39,960 --> 00:02:41,760
Let me give you a concrete example.

88
00:02:41,760 --> 00:02:44,680
A 2.3 terabyte, SAP HANA database backup

89
00:02:44,680 --> 00:02:46,600
on regular storage might take an hour.

90
00:02:46,600 --> 00:02:48,600
That's an hour of waiting and potential issues.

91
00:02:48,600 --> 00:02:49,840
On Azure NetApp files,

92
00:02:49,840 --> 00:02:52,000
the same backup completes in two minutes.

93
00:02:52,000 --> 00:02:53,680
Not a typo, two minutes.

94
00:02:53,680 --> 00:02:55,760
The issue isn't that Azure files is bad.

95
00:02:55,760 --> 00:02:58,080
It's a great service for what it's designed to do.

96
00:02:58,080 --> 00:02:59,640
But it's optimized for cost.

97
00:02:59,640 --> 00:03:00,560
Not peak performance.

98
00:03:00,560 --> 00:03:02,480
It gives you good enough speed at a reasonable price

99
00:03:02,480 --> 00:03:03,640
and that's fine for most workloads,

100
00:03:03,640 --> 00:03:06,080
but not all Azure NetApp files fills that gap.

101
00:03:06,080 --> 00:03:07,960
It's built for workloads that can't compromise

102
00:03:07,960 --> 00:03:09,520
on speed or consistency.

103
00:03:09,520 --> 00:03:11,920
When every millisecond counts, ANF is the answer.

104
00:03:11,920 --> 00:03:14,040
So who actually needs this kind of performance?

105
00:03:14,040 --> 00:03:16,080
Let's start with one of the biggest users.

106
00:03:16,080 --> 00:03:16,920
SAP HANA.

107
00:03:16,920 --> 00:03:18,760
Use case number one, SAP HANA.

108
00:03:18,760 --> 00:03:20,240
Let's talk about SAP HANA.

109
00:03:20,240 --> 00:03:22,200
If you're not in the enterprise database world,

110
00:03:22,200 --> 00:03:23,320
you might not have heard of it.

111
00:03:23,320 --> 00:03:25,040
But it's one of the most demanding workloads

112
00:03:25,040 --> 00:03:26,360
you can run in the cloud.

113
00:03:26,360 --> 00:03:28,400
SAP HANA is an in-memory database,

114
00:03:28,400 --> 00:03:30,800
meaning it keeps all its data in RAM for speed.

115
00:03:30,800 --> 00:03:32,320
But even though data lives in memory,

116
00:03:32,320 --> 00:03:34,120
HANA still needs ultra-fast storage

117
00:03:34,120 --> 00:03:35,720
for logs, backups, and snapshots.

118
00:03:35,720 --> 00:03:37,960
Those rights have to happen quickly and reliably.

119
00:03:37,960 --> 00:03:40,320
If storage can't keep up, the whole database slows down.

120
00:03:40,320 --> 00:03:43,360
That's why Azure NetApp files is SAP certified.

121
00:03:43,360 --> 00:03:47,160
It's listed in the official SAP HANA hardware directory,

122
00:03:47,160 --> 00:03:50,160
meaning it's been tested and approved by SAP themselves.

123
00:03:50,160 --> 00:03:51,120
That's not a small thing.

124
00:03:51,120 --> 00:03:54,080
SAP doesn't certify just any storage solution.

125
00:03:54,080 --> 00:03:57,280
They test it thoroughly and only the ones that pass make the list.

126
00:03:57,280 --> 00:03:59,120
What kind of performance are we talking about?

127
00:03:59,120 --> 00:04:01,240
Submily second latency consistently,

128
00:04:01,240 --> 00:04:04,520
and up to four times 500 might be per second of throughput per volume.

129
00:04:04,520 --> 00:04:05,640
To put that in perspective,

130
00:04:05,640 --> 00:04:08,280
SAP's minimum requirement for HANA log rights

131
00:04:08,280 --> 00:04:10,160
is under one millisecond of latency

132
00:04:10,160 --> 00:04:12,680
and ANF lives comfortably below that threshold.

133
00:04:12,680 --> 00:04:15,040
That matters because latency above one millisecond

134
00:04:15,040 --> 00:04:17,240
can slow down database transactions.

135
00:04:17,240 --> 00:04:19,160
When you're processing thousands of transactions

136
00:04:19,160 --> 00:04:21,280
per second, every extra millisecond adds up.

137
00:04:21,280 --> 00:04:23,280
Microsoft even built a special deployment tool

138
00:04:23,280 --> 00:04:25,640
called Application Volume Group for HANA.

139
00:04:25,640 --> 00:04:27,760
It optimizes volume layout by spreading them

140
00:04:27,760 --> 00:04:29,520
across multiple storage endpoints,

141
00:04:29,520 --> 00:04:31,920
so no single endpoint becomes a bottleneck.

142
00:04:31,920 --> 00:04:34,160
Think of it like having multiple lanes on a highway

143
00:04:34,160 --> 00:04:35,600
instead of one narrow road.

144
00:04:35,600 --> 00:04:37,680
And the backup numbers are worth talking about.

145
00:04:37,680 --> 00:04:40,240
A 2.3 terabyte HANA backup completes in about two minutes

146
00:04:40,240 --> 00:04:41,200
on ANF.

147
00:04:41,200 --> 00:04:44,920
On conventional storage, that same backup could take 30 to 60 minutes.

148
00:04:44,920 --> 00:04:46,040
That's not just a convenience.

149
00:04:46,040 --> 00:04:48,360
It changes what's possible with your backup windows.

150
00:04:48,360 --> 00:04:49,880
The cost side is interesting too.

151
00:04:49,880 --> 00:04:51,120
With flexible service levels,

152
00:04:51,120 --> 00:04:52,720
you can match performance exactly

153
00:04:52,720 --> 00:04:55,080
to what HANA needs without over-provisioning.

154
00:04:55,080 --> 00:04:56,640
You're not paying for extra capacity

155
00:04:56,640 --> 00:04:58,440
just to get the throughput you need.

156
00:04:58,440 --> 00:05:01,520
SAP is one big use case, but ANF also powers

157
00:05:01,520 --> 00:05:04,800
a very different kind of workload, high performance computing.

158
00:05:04,800 --> 00:05:07,200
High performance computing, HPC.

159
00:05:07,200 --> 00:05:09,720
High performance computing covers a lot of ground.

160
00:05:09,720 --> 00:05:13,200
Simulations, rendering, financial modeling, scientific research,

161
00:05:13,200 --> 00:05:15,640
anything where you're running massive parallel jobs

162
00:05:15,640 --> 00:05:18,200
across hundreds or even thousands of compute nodes.

163
00:05:18,200 --> 00:05:20,160
These workloads have a very specific need.

164
00:05:20,160 --> 00:05:23,520
They need shared file access with high throughput and low latency.

165
00:05:23,520 --> 00:05:25,640
Multiple nodes must read and write the same data sets

166
00:05:25,640 --> 00:05:26,680
at the same time.

167
00:05:26,680 --> 00:05:28,920
If your storage can't keep up, your compute nodes

168
00:05:28,920 --> 00:05:30,600
sit idle waiting for data.

169
00:05:30,600 --> 00:05:33,200
And idle compute time is wasted money.

170
00:05:33,200 --> 00:05:36,640
Azure NetApp files delivers up to 652,000 IOPS

171
00:05:36,640 --> 00:05:39,600
with under 2 milliseconds of latency in benchmark tests.

172
00:05:39,600 --> 00:05:41,800
That's a lot of input output operations.

173
00:05:41,800 --> 00:05:44,040
And it's fast enough that storage rarely

174
00:05:44,040 --> 00:05:45,440
becomes the bottleneck anymore.

175
00:05:45,440 --> 00:05:46,920
For really large data sets, there's

176
00:05:46,920 --> 00:05:48,480
the large volumes feature.

177
00:05:48,480 --> 00:05:51,280
It supports capacities up to two petabytes per volume.

178
00:05:51,280 --> 00:05:53,680
That's 2,000 terabytes in a single volume.

179
00:05:53,680 --> 00:05:55,560
Think about what that means for a research team

180
00:05:55,560 --> 00:05:57,520
working with massive simulation outputs,

181
00:05:57,520 --> 00:05:59,680
or a media studio rendering a feature film.

182
00:05:59,680 --> 00:06:01,800
Then this breakthrough mode, it pushes throughput up

183
00:06:01,800 --> 00:06:04,560
to 50 gigabits per second from a single large volume.

184
00:06:04,560 --> 00:06:07,120
That's enough bandwidth to move enormous data sets quickly.

185
00:06:07,120 --> 00:06:10,640
Here's a real world example, electronic design automation,

186
00:06:10,640 --> 00:06:13,520
or EDA in the chip design industry.

187
00:06:13,520 --> 00:06:16,680
Companies like Nvidia and AMD run thousands of simulations

188
00:06:16,680 --> 00:06:19,360
at once to verify chip designs before manufacturing.

189
00:06:19,360 --> 00:06:21,800
Each simulation reads and writes shared data.

190
00:06:21,800 --> 00:06:23,880
The storage system has to handle that concurrent load

191
00:06:23,880 --> 00:06:25,080
without slowing down.

192
00:06:25,080 --> 00:06:27,120
ANF is built for exactly that pattern.

193
00:06:27,120 --> 00:06:29,120
So why not just use Azure files for this?

194
00:06:29,120 --> 00:06:31,520
Because Azure files has file level throughput caps,

195
00:06:31,520 --> 00:06:33,800
300 megabytes per second, egress per file.

196
00:06:33,800 --> 00:06:36,520
That means even if your storage back end has more capacity,

197
00:06:36,520 --> 00:06:38,800
a single large file can't push past that limit.

198
00:06:38,800 --> 00:06:40,360
ANF has no file level caps.

199
00:06:40,360 --> 00:06:42,640
Each file can saturate the network connection.

200
00:06:42,640 --> 00:06:44,720
For workloads dealing with large simulation files,

201
00:06:44,720 --> 00:06:46,040
that difference matters.

202
00:06:46,040 --> 00:06:49,640
Microsoft's own guidance recommends ANF for HBC workloads

203
00:06:49,640 --> 00:06:53,320
up to about 4,000 cores and 6.5 gigabytes per second

204
00:06:53,320 --> 00:06:54,080
of throughput.

205
00:06:54,080 --> 00:06:56,280
Beyond that, you might need a different architecture,

206
00:06:56,280 --> 00:06:59,160
but for the vast majority of HBC scenarios,

207
00:06:59,160 --> 00:07:00,880
ANF fits the bill.

208
00:07:00,880 --> 00:07:03,720
Third major use case, virtual desktop infrastructure,

209
00:07:03,720 --> 00:07:05,760
where user experience is everything.

210
00:07:05,760 --> 00:07:07,960
Virtual desktop infrastructure, VDI.

211
00:07:07,960 --> 00:07:10,680
Now let's talk about something almost everyone deals with.

212
00:07:10,680 --> 00:07:11,960
The desktop experience.

213
00:07:11,960 --> 00:07:13,960
Virtual desktop infrastructure or VDI

214
00:07:13,960 --> 00:07:16,240
means hosting Windows desktops in the cloud,

215
00:07:16,240 --> 00:07:18,680
think as you are virtual desktop or Citrix.

216
00:07:18,680 --> 00:07:20,640
Instead of running a full PC on your desk,

217
00:07:20,640 --> 00:07:22,560
the desktop lives on a server somewhere

218
00:07:22,560 --> 00:07:24,160
and you connect to it remotely.

219
00:07:24,160 --> 00:07:25,040
Here's the challenge.

220
00:07:25,040 --> 00:07:27,720
User profiles and app data must be stored centrally

221
00:07:27,720 --> 00:07:29,040
and accessed quickly.

222
00:07:29,040 --> 00:07:31,640
Every time someone logs in, their profile has to load,

223
00:07:31,640 --> 00:07:33,960
settings, files, application data.

224
00:07:33,960 --> 00:07:36,160
If that storage is slow, the login is slow,

225
00:07:36,160 --> 00:07:38,400
and slow logins make people unhappy very fast.

226
00:07:38,400 --> 00:07:40,520
This is where ANF makes a real difference.

227
00:07:40,520 --> 00:07:43,160
Slow profile load times have been the number one complaint

228
00:07:43,160 --> 00:07:44,920
in VDI deployments for years.

229
00:07:44,920 --> 00:07:47,520
Users compare it to their old on-premises desktop.

230
00:07:47,520 --> 00:07:50,760
And if the cloud version feels slower, they notice immediately.

231
00:07:50,760 --> 00:07:54,280
Azure NetApp files solves this with high IOPS and low latency.

232
00:07:54,280 --> 00:07:56,400
And I'm not talking about theoretical improvements.

233
00:07:56,400 --> 00:07:58,480
Real-world results show logon times dropping

234
00:07:58,480 --> 00:08:01,080
from 20 to 30 seconds down to under five seconds

235
00:08:01,080 --> 00:08:02,960
when organizations switch from Azure files

236
00:08:02,960 --> 00:08:05,360
to ANF for their profile storage.

237
00:08:05,360 --> 00:08:07,440
That's the kind of improvement users actually feel.

238
00:08:07,440 --> 00:08:08,280
Why does it work so well?

239
00:08:08,280 --> 00:08:12,800
Because ANF supports up to 450,000 IOPS per volume,

240
00:08:12,800 --> 00:08:14,240
that matters when hundreds of users

241
00:08:14,240 --> 00:08:16,560
all log on at the same time in the morning.

242
00:08:16,560 --> 00:08:17,800
That's the logon storm.

243
00:08:17,800 --> 00:08:19,120
Everyone arrives at nine,

244
00:08:19,120 --> 00:08:21,880
and suddenly every profile needs to load simultaneously.

245
00:08:21,880 --> 00:08:24,400
A storage system that can't handle that concurrency

246
00:08:24,400 --> 00:08:25,720
will slow everyone down.

247
00:08:25,720 --> 00:08:27,240
ANF handles it.

248
00:08:27,240 --> 00:08:29,960
There's another feature that's incredibly useful for VDI.

249
00:08:29,960 --> 00:08:32,880
ANF supports up to 255 snapshots per volume.

250
00:08:32,880 --> 00:08:34,760
That means you can instantly revert

251
00:08:34,760 --> 00:08:36,680
a user's profile to yesterday's state.

252
00:08:36,680 --> 00:08:38,160
If someone's profile gets corrupted

253
00:08:38,160 --> 00:08:39,920
or a bad update breaks something,

254
00:08:39,920 --> 00:08:41,520
you don't have to restore from backup.

255
00:08:41,520 --> 00:08:43,960
You just point to yesterday's snapshot and it's done.

256
00:08:43,960 --> 00:08:45,680
That saves hours of support time

257
00:08:45,680 --> 00:08:47,880
and the reliability piece matters too.

258
00:08:47,880 --> 00:08:51,000
ANF comes with a 99.99% availability SLA.

259
00:08:51,000 --> 00:08:52,600
For mission-critical VDI deployments

260
00:08:52,600 --> 00:08:54,560
where downtime means lost productivity,

261
00:08:54,560 --> 00:08:56,320
that level of reliability is essential.

262
00:08:56,320 --> 00:08:58,120
Here's a cost angle you might not expect

263
00:08:58,120 --> 00:09:00,520
because ANF is so fast you can actually use smaller,

264
00:09:00,520 --> 00:09:03,080
cheaper virtual machines and still get good performance.

265
00:09:03,080 --> 00:09:04,400
The storage handles the heavy lifting

266
00:09:04,400 --> 00:09:05,800
so your compute doesn't have to.

267
00:09:05,800 --> 00:09:08,680
That can offset some of the premium storage cost.

268
00:09:08,680 --> 00:09:11,840
And you now see the three pillars SAP HPC VDI.

269
00:09:11,840 --> 00:09:15,240
But how does ANF actually compare to its cousin Azure files?

270
00:09:15,240 --> 00:09:17,960
How Azure NetApp files compares to Azure files?

271
00:09:17,960 --> 00:09:20,000
So both Azure NetApp files and Azure files

272
00:09:20,000 --> 00:09:21,760
are managed file shares in Azure.

273
00:09:21,760 --> 00:09:24,440
That means you don't patch servers or replace hardware.

274
00:09:24,440 --> 00:09:27,080
The real difference comes down to performance and price.

275
00:09:27,080 --> 00:09:28,560
Let's compare the raw numbers.

276
00:09:28,560 --> 00:09:31,600
Azure files premium caps at 100,000 IOPS per share,

277
00:09:31,600 --> 00:09:33,520
which is plenty for many workloads.

278
00:09:33,520 --> 00:09:36,720
But ANF hits up to 450,000 IOPS per volume,

279
00:09:36,720 --> 00:09:38,600
more than four times that ceiling.

280
00:09:38,600 --> 00:09:41,280
When you're running workloads that need serious concurrent access,

281
00:09:41,280 --> 00:09:42,840
that gap really matters.

282
00:09:42,840 --> 00:09:44,720
Latency tells a similar story.

283
00:09:44,720 --> 00:09:47,120
Azure files standard runs around 10 milliseconds

284
00:09:47,120 --> 00:09:49,640
and premium brings that down to two to three milliseconds.

285
00:09:49,640 --> 00:09:50,600
That's respectable.

286
00:09:50,600 --> 00:09:52,680
But ANF delivers sub millisecond latency

287
00:09:52,680 --> 00:09:55,520
around 0.5 milliseconds on the ultra tier.

288
00:09:55,520 --> 00:09:58,040
That's the difference between storage being a minor factor

289
00:09:58,040 --> 00:09:59,880
and storage being essentially invisible.

290
00:09:59,880 --> 00:10:02,600
Throughput is where the gap gets even wider.

291
00:10:02,600 --> 00:10:04,560
Azure files has file level caps.

292
00:10:04,560 --> 00:10:06,400
300 megabytes per second egress

293
00:10:06,400 --> 00:10:08,840
and 200 megabytes per second egress per file.

294
00:10:08,840 --> 00:10:11,000
So even if your backend has more capacity,

295
00:10:11,000 --> 00:10:13,720
a single large file can't push past that limit.

296
00:10:13,720 --> 00:10:15,520
ANF has no file level caps.

297
00:10:15,520 --> 00:10:18,760
Each file can use as much throughput as the network allows.

298
00:10:18,760 --> 00:10:20,000
And maximum share size,

299
00:10:20,000 --> 00:10:22,560
Azure files tops out at 100 terabytes per share.

300
00:10:22,560 --> 00:10:25,080
ANF goes up to two petabytes with large volumes.

301
00:10:25,080 --> 00:10:27,000
That's 20 times the capacity.

302
00:10:27,000 --> 00:10:28,200
So when do you use each one?

303
00:10:28,200 --> 00:10:30,880
Azure files is the right choice for general file sharing,

304
00:10:30,880 --> 00:10:32,520
department shares, backup targets,

305
00:10:32,520 --> 00:10:34,160
and cost sensitive workloads.

306
00:10:34,160 --> 00:10:35,480
Think of it as the sedan.

307
00:10:35,480 --> 00:10:37,760
Reliable affordable gets the job done.

308
00:10:37,760 --> 00:10:40,880
ANF is for workloads where latency and throughput are critical.

309
00:10:40,880 --> 00:10:44,280
SAPI Hana, Oracle, SQL Server, HPC, VDI.

310
00:10:44,280 --> 00:10:46,160
Any scenario where sub millisecond latency

311
00:10:46,160 --> 00:10:47,560
and high IOPS make a real difference

312
00:10:47,560 --> 00:10:48,920
to application performance.

313
00:10:48,920 --> 00:10:50,280
Now here's the thing about cost.

314
00:10:50,280 --> 00:10:53,200
Azure files is cheaper for most use cases and that's by design.

315
00:10:53,200 --> 00:10:56,080
But ANF can actually save money in specific scenarios.

316
00:10:56,080 --> 00:10:59,600
If it lets you use smaller VMs because the storage is faster,

317
00:10:59,600 --> 00:11:01,360
you save on compute costs.

318
00:11:01,360 --> 00:11:03,480
If it prevents over provisioning capacity,

319
00:11:03,480 --> 00:11:05,920
just to get enough throughput, you save on storage costs.

320
00:11:05,920 --> 00:11:08,240
So the total cost picture isn't always straightforward.

321
00:11:08,240 --> 00:11:11,080
There's one feature that changes the cost equation entirely,

322
00:11:11,080 --> 00:11:13,440
the flexible service level.

323
00:11:13,440 --> 00:11:16,200
The flexible service level, right sizing performance.

324
00:11:16,200 --> 00:11:17,960
Here's a feature that changes the cost equation.

325
00:11:17,960 --> 00:11:21,320
Traditionally, ANF capacity pools had a fixed ratio.

326
00:11:21,320 --> 00:11:23,760
The bigger your pool, the more throughput you got,

327
00:11:23,760 --> 00:11:26,360
and the smaller your pool, the less throughput you got.

328
00:11:26,360 --> 00:11:27,880
That sounds reasonable on the surface,

329
00:11:27,880 --> 00:11:29,440
but it created a real problem.

330
00:11:29,440 --> 00:11:32,200
Imagine you have a small database, say one terabyte,

331
00:11:32,200 --> 00:11:34,000
but it needs high throughput to run properly.

332
00:11:34,000 --> 00:11:36,640
Under the old model, you'd have to over provision capacity

333
00:11:36,640 --> 00:11:38,080
just to get enough performance.

334
00:11:38,080 --> 00:11:41,200
You might need to buy 64 terabytes of storage on the standard tier

335
00:11:41,200 --> 00:11:43,600
just to get the throughput that one terabyte actually needs

336
00:11:43,600 --> 00:11:45,800
with the other 63 terabytes sitting empty.

337
00:11:45,800 --> 00:11:47,440
You're paying for space you don't use.

338
00:11:47,440 --> 00:11:49,120
That's not efficient and it's not cheap.

339
00:11:49,120 --> 00:11:51,440
Flexible service level changes that completely.

340
00:11:51,440 --> 00:11:53,520
It decouples capacity from throughput,

341
00:11:53,520 --> 00:11:55,520
two independent knobs instead of one.

342
00:11:55,520 --> 00:11:57,040
You decide how much storage you need

343
00:11:57,040 --> 00:11:59,120
and separately how much performance you need.

344
00:11:59,120 --> 00:12:00,160
They don't have to match.

345
00:12:00,160 --> 00:12:01,920
So now you can have a one terabyte pool

346
00:12:01,920 --> 00:12:04,480
with one gigabyte per second of throughput.

347
00:12:04,480 --> 00:12:05,400
Under the old model,

348
00:12:05,400 --> 00:12:07,160
that same performance on the standard tier

349
00:12:07,160 --> 00:12:09,720
would have required 64 terabytes of capacity.

350
00:12:09,720 --> 00:12:11,520
That's a 64 to one difference.

351
00:12:11,520 --> 00:12:12,760
With flexible service level,

352
00:12:12,760 --> 00:12:14,320
you pay for exactly what you need.

353
00:12:14,320 --> 00:12:15,680
The cost savings are real.

354
00:12:15,680 --> 00:12:18,360
In many scenarios, you're looking at 30% or more

355
00:12:18,360 --> 00:12:20,920
compared to using the ultra tier for the same performance.

356
00:12:20,920 --> 00:12:23,880
And that's before you factor in reserve capacity discounts.

357
00:12:23,880 --> 00:12:26,200
The disaster recovery scenario makes this even clearer.

358
00:12:26,200 --> 00:12:29,320
Say you need 100 terabytes of capacity for a DR side,

359
00:12:29,320 --> 00:12:30,880
but you don't need much throughput

360
00:12:30,880 --> 00:12:32,520
until an actual failover happens.

361
00:12:32,520 --> 00:12:33,440
Under the old model,

362
00:12:33,440 --> 00:12:35,040
you'd have to provision for the performance

363
00:12:35,040 --> 00:12:36,360
you might need someday.

364
00:12:36,360 --> 00:12:37,760
With flexible service level,

365
00:12:37,760 --> 00:12:39,360
you pay for capacity only.

366
00:12:39,360 --> 00:12:43,120
128 megabytes per second baseline throughput and nothing more.

367
00:12:43,120 --> 00:12:44,360
When failover happens,

368
00:12:44,360 --> 00:12:46,560
you scale throughput up on demand.

369
00:12:46,560 --> 00:12:48,480
When it's over, you scale it back down

370
00:12:48,480 --> 00:12:50,600
after a 24 hour cool down period.

371
00:12:50,600 --> 00:12:51,520
Speaking of scaling,

372
00:12:51,520 --> 00:12:53,360
you can increase throughput whenever you need it

373
00:12:53,360 --> 00:12:55,000
within limits and after 24 hours,

374
00:12:55,000 --> 00:12:56,200
you can scale back down.

375
00:12:56,200 --> 00:12:58,120
That's perfect for handling peak loads.

376
00:12:58,120 --> 00:13:00,840
Month and processing migration windows, seasonal spikes,

377
00:13:00,840 --> 00:13:03,360
without permanently paying for that extra capacity.

378
00:13:03,360 --> 00:13:05,120
This feature is currently available in preview

379
00:13:05,120 --> 00:13:06,760
across all A and F regions.

380
00:13:06,760 --> 00:13:09,080
It's one of the most requested additions to the service

381
00:13:09,080 --> 00:13:10,960
and it's already changing how customers think

382
00:13:10,960 --> 00:13:12,160
about storage cost.

383
00:13:12,160 --> 00:13:14,320
That's the flexible service level in a nutshell,

384
00:13:14,320 --> 00:13:16,640
a simple change that solves a big problem.

385
00:13:16,640 --> 00:13:18,320
Connection section, putting it all together.

386
00:13:18,320 --> 00:13:20,200
So here's the aha moment.

387
00:13:20,200 --> 00:13:22,880
Azure NetApp files doesn't compete with Azure files.

388
00:13:22,880 --> 00:13:24,840
It fills a specific performance gap,

389
00:13:24,840 --> 00:13:26,960
a gap that matters for the right workloads.

390
00:13:26,960 --> 00:13:28,840
Now those three use cases we covered,

391
00:13:28,840 --> 00:13:32,080
SAP HANA, HPC, VDI, they all share one thing.

392
00:13:32,080 --> 00:13:33,720
They need consistent low latency,

393
00:13:33,720 --> 00:13:35,120
high throughput, file access.

394
00:13:35,120 --> 00:13:36,680
That's the common thread through all of them.

395
00:13:36,680 --> 00:13:38,840
Whether it's a database transaction,

396
00:13:38,840 --> 00:13:42,280
a simulation job, or a user logging into their desktop,

397
00:13:42,280 --> 00:13:45,080
the storage has to deliver without hesitation.

398
00:13:45,080 --> 00:13:46,160
No waiting around.

399
00:13:46,160 --> 00:13:48,880
Flexible service level makes that performance affordable.

400
00:13:48,880 --> 00:13:51,360
Instead of over provisioning capacity you don't need,

401
00:13:51,360 --> 00:13:53,040
you pay only for what you use.

402
00:13:53,040 --> 00:13:55,880
That changes the whole economics of high performance storage.

403
00:13:55,880 --> 00:13:57,120
It makes speed accessible.

404
00:13:57,120 --> 00:14:00,520
On top of that, ANF integrates with the rest of the Azure ecosystem.

405
00:14:00,520 --> 00:14:02,680
It uses EntraID for access control,

406
00:14:02,680 --> 00:14:04,080
snapshots handle backups,

407
00:14:04,080 --> 00:14:06,120
and replication covers disaster recovery.

408
00:14:06,120 --> 00:14:08,760
It's not an isolated tool, it's part of the broader platform.

409
00:14:08,760 --> 00:14:10,560
The real power lies in the combination,

410
00:14:10,560 --> 00:14:12,160
not in any single feature.

411
00:14:12,160 --> 00:14:15,280
Performance, flexibility, and managed simplicity altogether,

412
00:14:15,280 --> 00:14:16,640
you get enterprise grade storage

413
00:14:16,640 --> 00:14:18,320
without the enterprise grade overhead.

414
00:14:18,320 --> 00:14:21,080
Think of ANF as the specialized tool in your storage toolbox.

415
00:14:21,080 --> 00:14:23,400
You don't use it for everything, but when you need it,

416
00:14:23,400 --> 00:14:25,040
nothing else works as well.

417
00:14:25,040 --> 00:14:26,040
That's its job.

418
00:14:26,040 --> 00:14:27,240
Two things you can do right now.

419
00:14:27,240 --> 00:14:30,400
First, if you have a workload that complains about storage speed,

420
00:14:30,400 --> 00:14:33,320
like slow backups, laggy VDI, or long simulation times,

421
00:14:33,320 --> 00:14:34,400
take a closer look.

422
00:14:34,400 --> 00:14:36,920
Evaluate whether ANF could solve that bottleneck.

423
00:14:36,920 --> 00:14:39,000
It might be the fix you've been searching for.

424
00:14:39,000 --> 00:14:40,720
Second, head to the Azure website

425
00:14:40,720 --> 00:14:43,320
and use the Azure NetApp files cost calculator.

426
00:14:43,320 --> 00:14:46,440
Model your workload, especially with the flexible service level option.

427
00:14:46,440 --> 00:14:49,680
You might find that the performance you need costs less than you think.

428
00:14:49,680 --> 00:14:50,840
That's often the surprise.

429
00:14:50,840 --> 00:14:54,840
One caution though, don't migrate everything to ANF just because it's fast.

430
00:14:54,840 --> 00:14:56,320
Use it where it matters most.

431
00:14:56,320 --> 00:14:58,720
For general file shares and everyday workloads,

432
00:14:58,720 --> 00:15:00,920
Azure files is still the right choice.

433
00:15:00,920 --> 00:15:02,480
Save the sports car for the racetrack.

434
00:15:02,480 --> 00:15:03,480
That analogy works here.

435
00:15:03,480 --> 00:15:04,560
So what's the bottom line?

436
00:15:04,560 --> 00:15:07,360
Azure NetApp files is Azure's high performance file storage

437
00:15:07,360 --> 00:15:09,520
for workloads that can't compromise on speed.

438
00:15:09,520 --> 00:15:12,320
It's the specialized tool for the jobs that need it most.

439
00:15:12,320 --> 00:15:14,480
If this episode made ANF click for you,

440
00:15:14,480 --> 00:15:16,160
subscribe to Microsoft Knowledge Nuggets

441
00:15:16,160 --> 00:15:18,080
for more plain English explanations.

442
00:15:18,080 --> 00:15:20,480
Share it with someone starting their Azure journey.

443
00:15:20,480 --> 00:15:21,960
And drop a comment if something clicked.

444
00:15:21,960 --> 00:15:22,880
We always read them.

445
00:15:22,880 --> 00:15:23,800
I'm Mirko Peters.
